Carbon Nanotubes and Graphene for Electronics Applications 2012-2022

Technologies, Players & Opportunities

Brand new for April 2012

Show All Description Contents, Table & Figures List Pricing Related Content
Carbon Nanotubes (CNTs), graphene and their compounds exhibit extraordinary electrical properties for organic materials, and have a huge potential in electrical and electronic applications such as photovoltaics, sensors, semiconductor devices, displays, conductors, smart textiles and energy conversion devices (e.g., fuel cells, harvesters and batteries). This updated report brings all of this together, covering the latest work from over 100 organisations around the world to details of the latest progress applying the technologies. New developments, challenges and opportunities regarding material production and applications are provided.
The percentage of printed and partly printed electronics that is flexible 2012-2022
Source: IDTechEx
Carbon Nanotube and Graphene for Electronics Applications
Printable carbon nanotube inks and graphene-based inks are beginning to hit the market. However, carbon nanotubes (CNTs) have not yet met commercial expectations from a decade ago, and now hot on its heels is graphene. Graphene is considered a hot candidate for applications such as computers, displays, photovoltaics and flexible electronics.
Opportunities for Graphene
Graphene and its compounds are increasingly used to make transistors that show extremely good performance - a progress that comes with new cheaper production processes for the raw material. Transistors on the basis of graphene are considered to be potential successors for some silicon components currently in use.
Promise for CNTs
On the other hand, carbon nanotubes are still a strong focus for research. CNTs are used for making transistors and are applied as conductive layers for the rapidly growing touch screen market. Still considered a viable replacement for ITO transparent conductors in some applications, CNTs are not out of the game just yet. Fabricated as transparent conductive films (TCF), carbon nanotubes can potentially be used as a highly conductive, transparent and cost efficient alternative in flexible displays and touch screens, for instance. While the cost of carbon nanotubes was once prohibitive, it has been coming down in recent years as chemical companies build up manufacturing capacity.
Ten Year Forecasts
IDTechEx market forecasts indicate that CNT and graphene transistors and other applications may be commercially available in volume from 2016 onwards, according to the new report Carbon Nanotubes and Graphene for Electronics Applications 2012-2022. According to IDTechEx, the biggest opportunity for both materials is in printed and potentially printed electronics, where the value of these devices that partly incorporate these materials will reach over $63 billion in 2022.
Market forecast by component type for 2012-2022 in US $ billions
Source: IDTechEx
Challenges are material purity, device fabrication, and the need for other device materials such as suitable dielectrics. However, the opportunity is large, given the high performance, flexibility, transparency and printability. Companies that IDTechEx surveyed report growth rates as high as 300% over the next five years. New developments regarding the production of pure CNTs and the separation of conducting and semiconducting carbon nanotubes are given in this updated report.
Analyst access from IDTechEx
All report purchases include up to 30 minutes telephone time with an expert analyst who will help you link key findings in the report to the business issues you're addressing. This needs to be used within three months of purchasing the report.
Further information
If you have any questions about this report, please do not hesitate to contact our report team at or call one of our sales managers:

AMERICAS (USA): +1 617 577 7890
ASIA (Japan): +81 3 3216 7209
EUROPE (UK) +44 1223 812300
